Function:
►Routing,Cutting,Grinding,Polishing,Drilling,Milling,Engraving,Writing
Features:
►The mobile bridge structure ensures motion accuracy and easy loading/unloading operations.
►Liquid-cooled direct drive spindle,high stability and high precision,with the best technical specification in order to ensure optimum performance and ideal operating conditions.
►The machine is adaptable to any needs,thanks to the high configurability of the tool rack.
►Dynamic compensation of the polishing wheel for better machining quality.
►Ultra-thick and normalized welded monobloc steel base ensures sturdiness and rigidity for heavy duty operations and durability.
►High-thickness aluminum work table.The perfect planarity ensures ideal machining results.
►Working water collection tank integrated with the base,which reduce the machine footprint.
►Adopting imported square guide way, making the machine move steadily and have longer lifetime.
►Water cooling and constant torque spindle with the imported bearing, high power and low noise.
►Double-nut automatic disappear gap ball-screw.
►Break point and break knife continue engraving function, can engrave at any place as you need.
Technical parameters
Machine Model | LT1325 |
Max Working Size | 1300*2500mm |
Min Working Size | 250*250mm |
Machine Size | 2100*4400*2000mm |
Net Weight | 3000kg |
Machine Lathe | 300*300mm Thickness Rectangular Tube Weld |
Machine Worktable | 25mm Aluminum sheet |
XYZ Axis Dust-proof system | T-slot Aero-Aluminum profiles+Yellow PVC |
Spindle | 7.5kw Import Belt drive spindle |
Guide ways | 35mm HIWIN Linear Guideways |
Motors | YASKAWA SERVO MOTOR |
Control system | SYNTEC control system |
Transmission | Taiwan planetary gear |
Air Compression | 0.7Pa |
Tool Coner | BT40 |
Tool Positions | 10*1 |
Ball Screw Precision | ±0.05mm |
Electricity | 3P 380V/50HZ |
Total Power | 7.0kw |
Speed of Spindle | 0-9000rpm |
Process Thickness | 5-50mm |
X Axis Speed | 0-40m/min |
Z Axis Speed | 0-20m/min |
Y Axis Speed | 0-40m/min |
Package Dimension | 2200*4500*2300mm |
Gross Weight | 3200kg |
